| 材料 |
1 |
Stainless Steel SCS13/SCS14/SCS16 |
|
|
| 2 |
Other specific materials. |
|
|
| SCS23, Hastelloy, Duplex Stainless Steel |
|
|
| 温度 |
-10oC～119oC |
|
|
|
| 压力. |
1.6MPa |
|
|
|
| Pressure |
|
|
|
|
| 轴封 |
1 |
Gland packing. |
| Self and external flushing type. |
| 2 |
Mechanical seal. |
| a. |
Single mechanical seal. |
| |
Include balanced and unbalanced types. |
| |
Inside and outside types. |
| b. |
Double Mechanical Seal. |
| c. |
Additional Special Mechanical Seal may be installed on request. |
| |
When pumping temperature exceeds 80oC, cooler shall be provided. |
| 3 |
The shaft seal dimensions are structured to serve as gland packing and mechanical seal. |
| 轴承 |
Ball bearing (Oil bath system). |
|
|
|
