本多机工泵VNS/VNF(Metal-Less Pump)立式,悬臂轴型。非常可靠,低维护浆处理高容量油漆流通泵;每一天24小时循环的系统的理想选择。

材质 1 不锈钢SCS13/SCS14/SCS16.
2 Cast Iron FC200.
Ductile Iron FCD450 (For HC Series Pumps).
For cast-iron material the pump model is VNF.
3 Other specific materials.
SCS23, Nickel, Worthite and Hastelloy.
温度 ~200oC.
轴承 Upper side: Ball Bearings (Shield Type)
Lower side: Metal-Less Type
Maximum Length Standard 1.0m and 1.5m.
(size L) Length can be extended by adding supplementary suction pipe only when the Starting liquid level is above the impeller.
